Quick Details

  • Condition: New
  • CNC or Not: CNC
  • Place of Origin: Anhui, China (Mainland)
  • Brand Name: SUDA
  • Model Number: MG1325A
  • Voltage: 380V
  • Power(W): 9KW FOR SPINDLE MOTOR
  • Dimension(L*W*H): 3.1*2.28*2.15M PACKAGE SIZE
  • Weight: 2500KGS WITH PACKAGE
  • Certification: CE
  • Warranty: 1 year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Products Name: SUDA AUTO TOOL CHANGE CNC ROUTER FOR WOOD -MG1325A
  • Colour: Can optional
  • Standard: WHITE
  • driver system: Panasonic servo motors with drivers
  • rail guide: THK 25mm from Japan
  • tramsmitting way: rolling ball screw transmitting for Z axis
  • transmitting way: all axis by rack and gear
  • resolution: 0.01mm

Packaging & Delivery

Packaging Details in wooden cases for SUDA AUTO TOOL CHANGE CNC ROUTER FOR WOOD -MG1325A
Delivery Time 7 working days after payment for SUDA AUTO TOOL CHANGE CNC MACH

HEFEI SUDA NEW  AUTO TOOL CHANGE CNC ROUTER FOR WOOD -MG1325A



Product Description



Performance features



1.Integral welding body,high inflexibility structure design,material stress analysis and forming by heat treatment,avoid deformation.



2.Transmission part adopts high precision helical rack,THK linear rail from Japan,supplement with Japan Yaskawa servo system



and Taiwan professional deceleration device,ensure machine running smoothly in high speed,high precision,low noise.



3.Equipped with professional vacuum system,adopt integral adsorption base with the high  strength engineering plastics surface,onetime forming,adopt high power professional vacuum pump,strong adsorption capacity.



4.Imported high power spindle from Italy ,low sway in axial ,strong cutting force,long lifetime,low noise,with imported Geneva type library of 8pcs tool,high efficiency.



5.Industrial control system ,professional electronic parts,perfect function,stable  performance,strong compatibility of software .



Application:



Applicable to process kinds of boards,such as solid wood,acrylic,PVC board,shaving board,fireproof wood etc.Widely used in complex processing on door,cupboard,audio wood shell etc.



Technical data

item

MG1325A

MG1630A

MG2030A

Working size

1300*2500*210mm

1600*3000*210mm

2000*3000*210mm

Table size

1220*2440mm

1530*2940mm

1930*2940mm

Max.travel speed

X axis-30m/min,Y axis-30m/min,Z axis-20m/min

transmitting

X,Y-high accuracy helical gear,Z-rolling ball screw

Servo type

Japan Panasonic(YASKAWA is optional)

Spindle type

Italy 10kw ATC spindle motor

Spindle rev.

18000-24000rpm

Vacuum table

Matrix vacuum table

pump type

Moporo(Germany becker is optional)

Tool type

Bamboo Hat ATC

Tool magazine

8pcs(10pcs,12pcs is optional)

Controlling system

SYNTEC(OSAL is optional)

voltage

AC380V/3PH/50HZ

Machine size

2200*3100*2000mm

2500*3600*2000mm

2900*3600*2000mm

weight

2100KG

2900KG

3400KG

Note:Any changes of technical parameters without notice,price changed with different configuration and size.






Packaging & Shipping



Our Services

Guarantee & Aftersale Service:



1.Guarantee for one year



2.24-hour technical support by email or on line



3.User-friendly English manual for machine using and maintaining



4.Free technician training for large customers.

5. Provide Engineers oversea training for our customers .

Company Information

TONGXING TECHNOLOGY DEVELOPMENT Co., LTD. Lines in one of Chinese science and technology cities-Hefei. It has been researching and manufacturing the CNC machinery for advertising making and mould processing since 1992.

Great deals of scientific and technical talents supply a fertile soil for the developing of technology manufacturing industry. With the rapid economic growth in China, the science and technology city- Hefei, is growing into one of the cities with greatest development potential.
Up to date, Tongxing company owns three production bases and one national advanced CNC Laboratory, which sum to 80,000 square meters.

Tongxing always pursue the two conceptions “Supply Excellent Products” and “Create Value for Customers”, which has been recognized both in and outside China.The main products are as follows: Suda Vanguard Series large format CNC Engravers, Suda Powerful series CNC engravers, Suda Luck Series CNC engravers, Suda speedy CNC Engravers, Suda Cutting Plotter, Suda Laser Machine and Suda Cylinder CNC Engraver, total 16 series, mote than 70 models.


The main products especially Suda Large Format CNC Router-which is the first National big format CNC Router in the market have been awarded “High & New Technology Products” by the government, at the same time, Tongxing Company is voted as “State Level High-tech Enterprise”.

Our marketing network has covered all Chinese provinces and municipalities, including Hong Kong ,Taiwan & Macao besides Main Land. Till now, Suda products have been exported to more than 100 countries and regions like Russia, Japan, South-east Asia, Mid-east, Europe and America etc.

FAQ

Q1.How do you get the best price?





As you may know,the different type of CNC machine apply to the different material,and the different model apply to the different material.



Please tell me whats material you want to cutting or engraving ?

And whats MAX size of carved material ?



Then I wil recommand the most suitable model and the best price for you.





Q2.In case of failure,how to do?







Call us----our enginners are online for 24-hours,and ready to serve you.

Replacement of damaged parts for free---For more information,please contact us

The CD and operation manual----It show the most common failure in working processing and how to solve this problems.



Certifications

We have CE certificate for our all machines















Packaging

Normally for all SUDA machines with Plywood packages . Smaller machines with a seperately packages

if customer buy more set machines and want to loading into the container, We can make the package as metal holder ....
